Bedford 20-3010 Repair Kit is Graco 24F969 aftermarket replacement

Graco 24F969 180cc Xtreme 750 Repair Kit — AfterMarket by Bedford Precision

This professional rebuild set replaces Graco 24F969 and is supplied as an AfterMarket by Bedford Precision Parts of the OEM product. Use it to restore the packing stack and related wear components in Xtreme 750 pumps with 180 cc lowers so your system can re-prime quickly, hold stable pressure, and deliver a clean, consistent finish to your production paint sprayer guns.

Where it fits & typical use

• Fits: Graco Xtreme 750 pump configurations that specify a 180 cc lower and call for kit 24F969 (confirm ratio, lower size, and bill of materials in your service manual).
• Used in: Industrial finishing, fabrication, protective coatings, and booth operations supplying contractor and plant-floor rigs stocked with graco paint sprayer parts.

What this kit does

• Replaces worn upper/lower packings, seals, and related items that cause leakage, pulsation, or pressure loss.
• Helps maintain uniform film build and smooth atomization across shifts.
• Built to match OEM form and function for confident fitment and repeatable results with your graco airless sprayer parts inventory.

Why choose this Bedford aftermarket solution

• Value-driven alternative that supports planned maintenance without compromising performance.
• Consistent materials and dimensions for predictable rebuild quality in mixed-brand shops carrying wagner paint sprayer parts and binks sprayer repair parts alongside Graco lines.
• Backed by Bedford Precision’s long-standing focus on pump and spray-system service components.

What you receive*

• Aftermarket repair kit replacing Graco 24F969 for Xtreme 750 (180 cc) lowers
• Typical contents include packing sets, backup rings, O-rings, and related wear items for a standard lower-end service

*Exact contents may vary by manufacturer’s supply. Inspect piston/rod, checks, balls, and seats; replace additional worn parts as needed. Follow torque and lubrication specs in your service documentation.

Installation notes

• Clean all wetted parts and mating surfaces; verify solvent/material compatibility.
• Lubricate per the manual, torque to spec, then perform leak/pressure tests and a pattern check before returning to production.

Cross-reference: Graco 24F969 (Xtreme 750, 180 cc lower). Always confirm against your exact model/serial and parts list.
