Bedford 20-3442 is Graco 25D262 Kit aftermarket replacement

Graco 25D262 Xtreme 290cc Kit (TFE/PE) — AfterMarket by Bedford Precision Parts

This page features the Bedford Precision Parts 20‑3442 kit—an AfterMarket replacement of the OEM Graco 25D262. It’s engineered for the Graco Xtreme (NXT) 290 cc lower pump, delivering OEM‑level fit and performance for professional coating applications.

What it fits & where it’s used

Designed for the Graco Xtreme 290 cc lower, this full repair kit refreshes the fluid section used in heavy‑duty, air‑operated sprayers handling industrial paints, primers, and protective coatings on structural steel, tanks, and general fabrication. If you’re experiencing pressure loss, pulsation, or poor atomization, a packing rebuild with this kit restores sealing and spray consistency.

Materials & what’s included

The 25D262 specification pairs UHMWPE and PTFE elements for chemical resistance and durability below 140 °F (60 °C). Typical contents include throat and piston packings sized for the 290 cc lower (e.g., four UHMWPE and three PTFE for the throat; three UHMWPE and two PTFE for the piston), plus related seals required for a full rebuild.

Why choose Bedford AfterMarket

• Direct replacement for Graco 25D262 with Bedford P/N 20‑3442—built to rigorous specs for reliable uptime.

• Quality components designed to handle demanding, daily use in spraying environments.

Pro tips for a successful rebuild

1. Safely depressurize and verify the pressure relief valve is functioning before teardown. Review your Graco service manual for torque and stack orientation.

2. Replace worn check components and packings together to maximize service life; re‑lube per manual during reassembly.
3. After re‑priming, validate pattern quality with your paint sprayer guns and dial in your airless spray gun tips to match coating viscosity and target finish.
